CSB
HBA2-G2 .3.jpg
HBA2-G2 .4.jpgCSB
Contractor - Bay Light
The CSB features a single-piece die-cast aluminum housing, suitable for interior/exterior, wet, high pressure washdown applications. It features a clear polycarbonate lens and symmetric LED board layout for uniform illumination. The luminaire has a 70 CRI Lumileds LED, a long-life 50,000 hr LED, and optional dimming sensors.
Resources
CONSTRUCTION
Single piece die-cast aluminum housing, maximizes heat dissipation and life expectancy of the luminaire.
Suitable for interior/exterior, wet, high pressure washdown applications.
OPTICS
Standard clear polycarbonate lens protects LEDs against solid and liquid impact, symmetric LED board layout offers maximum uniformity illumination.
ELECTRICAL
70 CRI Lumileds LED.
-40°C up to 45°C (-40°F up to 113°F) maximum operating temperature.
Long-life 50,000 hr LED at L70.
Available with CCT / Output selectable function.
Universal Input 120-277V, 0-10V dimming, output 36V-42V, with 12V AUX output, 50/60Hz, <15% THD, 0.9 power factor.
Optional dimming sensor for occupancy and ambient light level detection.
SENSORS (OPTIONAL)
SENSOR-ANT-6-4T Plug-N-Play PIR on/off/dimming/photosensing.
SENSOR-BLE-6-4T Integral PIR ALS Control bluetooth/on/off/dimming/photosensing.
MOUNTING
Standard Snap Hook w/Safety Cable included.
Optional 3/4” Pipe Adapter to Pendant Mount Application.
Optional Yoke mount bracket.
STANDARD FINISH
Corrosion resistant semi-gloss Black or White finish.
CERTIFICATION
Wet location label standard.
Meets Buy America Act requirements. Available for BAA Compliant projects.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
For Emergency application, equipment with UL924 certified battery packs.
DLC® Premium (DesignLights Consortium Qualified)
WARRANTY
5 year warranty, see Limited Warranty for additional information.
Single piece die-cast aluminum housing, maximizes heat dissipation and life expectancy of the luminaire.
Suitable for interior/exterior, wet, high pressure washdown applications.
OPTICS
Standard clear polycarbonate lens protects LEDs against solid and liquid impact, symmetric LED board layout offers maximum uniformity illumination.
ELECTRICAL
70 CRI Lumileds LED.
-40°C up to 45°C (-40°F up to 113°F) maximum operating temperature.
Long-life 50,000 hr LED at L70.
Available with CCT / Output selectable function.
Universal Input 120-277V, 0-10V dimming, output 36V-42V, with 12V AUX output, 50/60Hz, <15% THD, 0.9 power factor.
Optional dimming sensor for occupancy and ambient light level detection.
SENSORS (OPTIONAL)
SENSOR-ANT-6-4T Plug-N-Play PIR on/off/dimming/photosensing.
SENSOR-BLE-6-4T Integral PIR ALS Control bluetooth/on/off/dimming/photosensing.
MOUNTING
Standard Snap Hook w/Safety Cable included.
Optional 3/4” Pipe Adapter to Pendant Mount Application.
Optional Yoke mount bracket.
STANDARD FINISH
Corrosion resistant semi-gloss Black or White finish.
CERTIFICATION
Wet location label standard.
Meets Buy America Act requirements. Available for BAA Compliant projects.
All luminaires are built to UL1598 standards and bear appropriate cULus labels.
For Emergency application, equipment with UL924 certified battery packs.
DLC® Premium (DesignLights Consortium Qualified)
WARRANTY
5 year warranty, see Limited Warranty for additional information.
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
CRI
- 70 CRI
Color / Finish
- Black
- White
Controls Options
- Daylight Sensor
Dimming Protocol
- 0-10 V
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- UL
- cULus
Lumens
- 16500 Lm
- 24000 Lm
- 30000 Lm
- 36000 Lm
Materials
- Die-Cast Aluminum
Ratings & Compliance
- Buy American Act (BAA)
- DLC
Special Programs
- Quick Ship
Voltage
- 12 V
- 120-277 V
- 347-480 V
Warranty
- 5 yr
Watts
- 92 w
- 138 w
- 184 w
- 230 w
